In Massachusetts, the diamond comes first. Our sales and shipping record for the state, one row per organization, model and city or town, puts two outdoor baseball and softball scoreboards at the top: the LX1030 and the LX1060. Baseball outnumbers every other sport in the record. The third-most-shipped model is a different product altogether, the LX2160, a pair of indoor basketball shot clocks.

The split points a buyer toward two separate questions. On the field, the choice between the two leading models comes down to the cabinet, and each model's own spec sheet sets out what the smaller one gives up. In the gym, the question is what a shot clock pair shows at each basket that the main scoreboard does not.

The record says what we sold and shipped. It does not say why. I would treat the counts as a guide to what Massachusetts organizations order, then confirm the pitching and foul rules your games follow before any order goes in.

What does our Massachusetts sales and shipping record show?

Our Massachusetts sales and shipping record holds 246 records across 127 cities and towns, from 2000 to 2025, and baseball leads every other sport at 103 records.

Three steps turn the record into a buying aid:

1. Find your sport in the counts below.
2. Match the leading models to that sport, because an outfield scoreboard and a gym accessory solve different problems.
3. Read each model's own spec sheet before comparing, since no figure carries from one model to another.

Massachusetts ranks twenty-first of 50 states by units shipped in our data. The sport split below comes straight from the state record, with no figure recalculated.

Our review of the record counts each model by its LX equivalent, so the variant spellings of one model fold into that model. The LX1030 leads at 27 records, followed by the LX1060 at 23, the LX2160 at 17, the LX2350 at 15 and the LX1050 at 13, out of 56 distinct models recorded in the state. Each record is one row per organization, model and city. It counts what we sold and shipped, not what stands on a field today. The record also does not say why any scoreboard was bought or what it replaced.

Contrary to the image of the scoreboard as a football stadium fixture, football sits well behind both the diamond and the gym in this record. The diamond leads. The gym comes second, and readers planning one can start with our basketball scoreboards.

Read side by side, 2 sources explain why the diamond deserves the closest look. Our state record puts baseball first, and Little League publishes pitch count breakdowns by league age and days-of-rest thresholds for each division of play. In practice, the same diamond can host divisions playing under different pitching rules. The scoreboard serves all of them.

For a buyer, the pattern is a starting point, not a verdict. Your sport and your field decide the model.

LX1030 or LX1060: what does a buyer give up and gain with the smaller cabinet?

The LX1030 and LX1060 are both outdoor baseball and softball scoreboards with 18-inch digits, and the LX1030 fits that same digit height into an 8 ft x 4 ft cabinet.

The LX1030 is the newer layout. Its model page says the 8 ft x 4 ft design debuted several years ago, sits in size between the LX1050 and the LX1060, and has proven a good fit for little leagues and high schools. It carries LED digits for Runs and Inning, bullet-style indicators for Ball, Strike and Out, and the MM console in the package.

The LX1060 is the long-standing layout. Its model page traces the design to the electro-mechanical scoreboards Electro-Mech built in the 1960s and notes that a 10 ft x 5 ft baseball model laid out like it has always been in the catalog. The same page names a single cabinet and the MM style console.

Our review of the two spec sheets puts the whole difference in the cabinet. Digit height, indicator size and base amperage match. The LX1060 adds cabinet area, weight and slightly taller captions, and its options list includes Electronic Team Names, which our data from the LX1060-ETN spec sheet shows raising the draw for that variant. The LX1030 sheet lists no such option.

So the trade is plain. Choosing the LX1030 gives up cabinet area, caption size and the team-name option. It keeps the full digit height, and digit height is what sets reading distance. A smaller cabinet is not a smaller digit.

Both sheets list the same standard build: heavy duty extruded aluminum framing, mounting hardware for two posts without on-site fabrication, a choice of 18 standard paint colors, LED circuits conformal coated for outdoor use, and the simplified 15-key control console. I would point a buyer who wants team names, or a larger cabinet face, toward the LX1060. A buyer who values the lighter cabinet has a sound reason to pick the LX1030.

The record does not say why any Massachusetts buyer chose one model over the other, so the spec sheets, not the counts, should settle the decision. Where the same complex also hosts fall sports, compare our soccer scoreboards before committing.

How can you preview the LX1030 before you order one?

The LX1030, the most-shipped model in our Massachusetts record, is best previewed on its model page and spec sheet, which show the Ball, Strike and Out indicators and the listed options.

Read the model page first. Our review of the LX1030 model page places the scoreboard between the LX1050 and the LX1060 in size, and it describes bullet-style indicators for Ball, Strike and Out beside the Runs and Inning digits. The page adds that the layout debuted several years ago and has gained popularity among the company's customers since.

The spec sheet then answers the questions a model page leaves open. Specifically, its optional equipment list shows how far the cabinet can be customized:

• ID panels with custom graphics, in a variety of sizes, shapes and styles, mounted above or below the scoreboard.
• Extended configurations that build ID panels into the left or right side of the cabinet.
• Stadium Sound System packages and full color video panels, listed as options rather than standard equipment.

In my view, a buyer who marks up both documents before the first call gets a sharper quote. Mark the options your field needs. Cross out the ones it does not. The Electro-Mech team can then price the scoreboard you described, not a generic one.

What does a pair of LX2160 shot clocks do that a main scoreboard does not?

A pair of LX2160 shot clocks puts 12-inch red shot time digits behind each backboard, with visual horn indicators, an internal horn and an output for backboard light bars.

Here the record turns. The two leaders live outdoors on the diamond, yet the third most-shipped model in Massachusetts is a small indoor accessory for basketball, the state's second sport. The LX2160 is not a second scoreboard. It is an accessory display set that works alongside the gym's main scoreboard.

A shot clock counts down the time the team in possession has to shoot. The LX2160 model page notes that the shot clock arrived in the 1950s, and describes the model as two shot clock displays designed to mount behind the backboards. Built-in mounting points let each cabinet attach to a wall or to the structure supporting the backboard, and the spec sheet adds clamping hardware for a vertical support plus tapped side attachment points.

The spec sheet lists what the pair adds at each end of the court:

• Shot time at the basket: 12-inch red digits on a 24 in x 27 in cabinet weighing 20 lb, each display drawing 0.3 amps.
• An end-of-period signal: 4-inch Visual Horn indicators, plus an output port for the optional backboard light bar kit, which lights when the main scoreboard horn sounds at the end of a period.
• Its own horn: an internal horn in the cabinet, with matte black faces painted for maximum contrast.
• Room to grow: a data output port on each cabinet that supports daisy chaining additional displays.

Control stays with the main scoreboard. A handheld three-button switch assembly attaches to the main control console for the shot clock features, and the model page states that shot timers are priced without a control console. Our review of the LX2160 spec sheet shows two ways to connect: up to 1,000 feet of data cable per display, or ScoreLink Wireless RF with two receiver units.

The contrast with the diamond is the point. Each sport brings its own timing, and youth baseball's pitching limits move with league age and days of rest. Basketball runs on shot time. The LX2160 puts that number where the players under each basket can see it.

For a gym that already has a main scoreboard, the shot clock pair is the natural next step. Operators can find setup documents on our scoreboard manuals page before ordering.

I would put the LX1030 into a purchase request one decision per line. The highlighted lines are options. Everything else ships in the standard package the LX1030 spec sheet lists.

Model:          LX1030, outdoor baseball / softball
Console (std):  MM console, simplified 15-key
Console (opt):  full-sized 37-key with LCD display
Link (std):     junction box and patch cable, hardwired
Link (opt):     ScoreLink Wireless RF modem system
Face (opt):     team name in place of HOME

Naming the console and the control link up front keeps either one from being assumed.

What can a shipping record tell you about how long a scoreboard lasts?

Our shipping record can date a purchase but not a lifespan: each entry is a scoreboard we sold and shipped, and the record is silent on installation, current use, replacement and cost.

The shot clock puzzle shows the limit of counting orders. A count says what left our hands. It cannot say what happened next.

• What an entry can tell you: which model shipped, for which sport, to which organization and city, and on what date.
• What an entry cannot tell you: whether the scoreboard went up, whether it still runs, what it replaced, or what it cost.

A ship date marks when a scoreboard left us, not when it went up or when it came down. Two entries for the same organization years apart show two orders. They do not show a replacement.

Ownership after the sale matters as much as the hardware. In a 2021 r/k12sysadmin thread, the replacement of an aging high school football scoreboard landed with a school's IT department, not athletics or facilities. Whoever inherits the scoreboard decides how well it is looked after.

So the honest answer to how long a scoreboard lasts sits outside any order count. I would read our record as proof of where demand has been, and read each model's spec sheet, its construction and its support terms, as the evidence for durability. A buyer comparing outdoor models should ask for those documents first.

What should a Massachusetts buyer check on pitch counts, ball-strike displays and foul rules before ordering?

Before ordering, confirm which pitching policy and foul rules govern your games, since every state association sets its own pitch-count policy and high school team fouls now reset each quarter.

The baseball rule starts with the NFHS. In 2016 the NFHS Baseball Rules Committee revised Rule 6-2-6 so that each member state association develops its own pitching restriction policy, based on the number of pitches thrown in a game, with a required rest period between appearances. The limits themselves are set at the state level. A Massachusetts school should confirm the current policy with the Massachusetts Interscholastic Athletic Association before planning around any number.

Youth play adds another layer. Little League publishes pitch count breakdowns by league age and days-of-rest thresholds for each division of play. One diamond can therefore carry more than one pitching rule in a single week, depending on who is on the field.

The gym changed more recently. Since the 2023-24 season, NFHS Rule 4-8-1 awards two free throws for all common fouls once the opponent commits five fouls in a quarter, and team fouls reset at the end of each quarter. The change eliminated the one-and-one, which had been counted by the half.

Four steps turn those rules into a buying decision:

1. Name the rulebook for every level that plays at the site: the state association's policy for high school games, and the league's own rules for youth games.
2. Decide who tracks pitches during a game, and whether you want that count shown to the crowd or kept at the bench.
3. Check which fields a model's spec sheet actually lists, ball, strike and out indicators included, before assuming a scoreboard can display something.
4. For a gym, confirm that the console and scoreboard present team fouls and the bonus by quarter, in line with Rule 4-8-1.

Buyers often search for baseball scoreboards with pitch count and ball-strike displays as if one model answers both. The rulebook decides which numbers matter. The spec sheet decides which numbers a scoreboard can show.

My recommendation is to settle the rulebook question before the cabinet size question. Put each of these points in writing with the quote request, so every answer is tied to a model number rather than a general promise. Rules change at their own pace; a scoreboard should be chosen for the rules your games are played under today.

What should a Massachusetts buyer take from this record?

Settle the console and the rules your games follow, then choose the cabinet; in Massachusetts that order holds on the diamond and in the gym alike.

Baseball's 103 of our 246 Massachusetts records make it the largest single sport in the state's shipping record. The LX1030 and LX1060 share the MM console. The cabinet is the real choice there.

The gym runs the other way. Because the LX2160 pair works through the gym's main control console by way of a handheld three-button switch, I would confirm what that console handles before adding shot clocks. Treat that as the first step toward the pair, not a reason to wait on it.

My advice for the next order is plain. Name the console, the control link and the governing rules on the request, then ask the Electro-Mech team for a quote built on those three answers.
