One leg assembly with wheels One leg assembly without wheels Four 2-inch 1/2-13 UNC bolts
What you will need:
Two people (for lifting) A 3/4-inch wrench An Electro-Mech portable scoreboard
72 Industrial Boulevard Wrightsville, GA 31096 Phone: (800) 445-7843 Fax: (800) 864-0212 www.electro-mech.com
April 3, 2012
Revision 1
Overview
If you ordered this kit along with your scoreboard, the bolts will arrive threaded into the mounting point on each side of the scoreboard.
tached to either side.
tions.
Use 3/4-wrench to tighten the bolts. A torque of 30 ft . lbs. is suffi cient to keep the legs in place under typical condi- tions.
One person should lift the scoreboard cabinet into po- sition using the attached leg assembly as a pivot while the other attaches the second leg.
Attach the leg assembly WITH wheels. Th e wheels may be oriented toward the inside or outside of the scoreboard cabinet.
Aft er a fi nal check on all four bolts, use the leg assembly WITHOUT wheels as a han- dle to guide your scoreboard to its fi nal position.
